| Display Specification | |||
| Diagonal Display Size | 65″ / 75″ / 85″ / 86″ / 98″ | ||
| LED Brand | CSOT / BOE / AUO | ||
| Bezel Color | Aluminum frame (Black & Grey) | ||
| Backlight | Direct Type LED | ||
| Active Area (mm) | 1428.48×803.52 / 1649.66×927.93 / 1872×1053 / 1895.04×1065.96 / 2158.85×1214.35 | ||
| Resolution | 3840×2160 (UHD) | ||
| Aspect Ratio | 16:9 | ||
| Contrast Ratio | 1200:1 / 4000:1 | ||
| Brightness | ≥450 cd/m² | ||
| Viewing Angle | 178° | ||
| Glass Hardness | Mohs 7 Level, 4mm Anti-Glare Glass | ||
| Touch Panel | |||
| Technology | IR Touch | ||
| Touch Points | 40 (Windows) / 20 (Android) | ||
| Accuracy | ±2mm (Windows) | ||
| Recognition | Finger or Passive Stylus | ||
| Response Rate | <4ms (single) / <10ms (multi) | ||
| System & Connectivity | |||
| OPS Slot | OPS & OPS-C Intel Standard | ||
| WiFi / Bluetooth | WiFi 5, Bluetooth 5.0 | ||
| System Support | Windows, Mac, Android, Linux, Chrome OS | ||
| Android Version | Android 14.0 (RK3576, Octa-core CPU, 8GB RAM, 128GB ROM) | ||
| Front Connectivity | |||
| Ports | USB3.0×3, HDMI2.0×1, Type-C×1, Touch USB-B×1 | ||
| Buttons | Indicator (Red/Blue), Light Sensor, ECO, Power | ||
| Speaker | 15W×2 (Subwoofer optional, max 60W) | ||
| Rear Connectivity | |||
| Ports | RJ45 IN/OUT, HDMI IN×2, DP IN, RS232, USB2.0/3.0, TYPE-C, MIC IN, TF Slot, SPDIF, Earphone Out | ||
| Physical Specification | |||
| Net Weight (kg±2) | 43 / 52 / 80 / 92 | ||
| Gross Weight (kg±2) | 53 / 62 / 93 / 110 | ||
| Overall Size (mm) | 1483.8×886.9×115.8 ~ 2216×1318.4×97.9 | ||
| Carton Size (mm) | 1615.8×1012×220 ~ 2356×1441.5×230 | ||
| VESA Mount | 500×400 / 600×400 / 800×400 / 1000×400 | ||
| Electrical | |||
| Input Voltage | 90–264V AC | ||
| Power (Max) | 200W / 240W / 360W / 610W | ||
| Standby Power | <0.5W | ||
| Environment | |||
| Operating Temp | 0℃ – 40℃ | ||
| Storage Temp | -20℃ – 60℃ | ||
| Humidity | 10–80% (operation), 10–90% (storage) | ||
| Optional Modules | |||
| OPS PC | Intel i3/i5/i7, 8GB RAM, 128GB SSD (256GB/512GB optional) | ||
| Camera | UHD 16MP/48MP, 120° FOV, Built-in Top Frame | ||
| Microphone | 8 Array, 10m Voice Pickup | ||
| Accessories | Pen, Remote, Power Cable, Wall Mount Kit, Optional Dongle or Mobile Cart | ||
Interactive displays are commonly used in education, business meetings, training sessions, exhibitions, and command centers. They support touch, writing, and multimedia presentations to enhance collaboration and engagement.
Yes. Many interactive displays run on Android OS and allow basic usage such as whiteboarding, file browsing, and screen mirroring without connecting to a PC. For advanced applications, you can connect a laptop or OPS module.
Interactive whiteboards require projectors and external components, while interactive displays are all-in-one flat panels with built-in touch, display, and computing systems.
Yes, we offer a standard warranty (typically 1–3 years) and lifetime remote support. Onsite service or replacement policies vary by region. Please contact our support team for specific terms.
Most models run Android, and many support dual systems (Android + Windows OPS). External devices like macOS, ChromeOS, and Linux can also be connected via HDMI and USB.
It depends on your room size and audience:
65” Interactive Display for small rooms (under 15 people)
75” Interactive Display for mid-sized classrooms or boardrooms
86” Interactive Display for large lecture halls or auditoriums
- 100” Interactive Display – Best suited for large venues such as auditoriums, exhibition halls, or corporate training centers (50+ people), where long viewing distances and impactful visuals are required.
Yes. Interactive displays can integrate with platforms like Zoom, Microsoft Teams, and Google Meet, especially when paired with cameras, microphones, and OPS computers.
We offer global delivery with secure packaging. For bulk orders, we can provide installation guidance or onsite setup service via local partners.
Yes. Our displays support 10-point or 20-point touch, allowing multiple users to interact simultaneously—ideal for group activities or collaborative work.
Yes. We support OEM/ODM services, including UI customization, pre-installed apps, and logo branding.
We offer full OEM/ODM services for all models of our interactive displays. Whether you’re a distributor, brand owner, or project integrator, we can tailor the product to meet your market needs. This includes custom hardware configurations, your own brand logo, personalized packaging, and software language localization—such as Spanish, Arabic, Indonesian, and more. Our engineering and production teams work closely with you to ensure seamless customization, while maintaining high standards of quality and fast lead times. From visual identity to system interface, we help you create a truly localized product that stands out in your market. With experience serving clients across education, corporate, and government sectors, we’re here to support your brand expansion and business growth. Whether you need just a few adjustments or full private-label solutions, China Chip Depot is ready to be your trusted OEM/ODM partner in the interactive display industry.
